Đầu dẫn hướng cho máy cắt dây EDM GF Agie Charmilles
Đầu dẫn hướng cho máy cắt dây EDM GF Agie Charmilles
| Various | |||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application |
 |
F307 | A290-8101-X761 | 75x56x66 | Lower | α-A. B series Guide base |
 |
F307A | 75x56x66 | Lower | α-iC series Guide base | |
 |
F307B | A290-8110-X761 | 75x56x66 | Lower | α-iA. iB. iC series Guide base |
 |
F307C | 81x56x66 | Lower | α.-iA. iB. iC series Guide base | |
| F308 | A290-8102-X393 | Wire guide | α-A. C series | ||
 |
F321 | 64x42x23T | Upper | W0 series | |
 |
F322 | 56x43x15T | Lower | W0 series | |
 |
F323 | A290-8110-X600 | 27x70x35T | Lower | α-A. C series Ref. F305B |
 |
F324 | A290-8102-X600 | 27x70x48T | Lower | α-A. C series Ref. F305A |
 |
F400 | A97L-0001-0670 | Bearing | Bearing 1260Z for F401 & F402 Ref. SSLF1260ZZ | |
 |
F401 | A290-8004-X713 | Φ49xΦ6.5x6T | Lower | W series Wire sub roller (Stainless housing+Plastic roller) |
 |
F401B | A290-8004-X713 | Φ49xΦ6.5x6T | Lower | W series Wire sub roller (Brass housing+Plastic roller) |
 |
F401B SET | A290-8004-V316 | Φ49xΦ6.5x6T | Lower | W series Wire sub roller (Brass housing+Plastic roller) |
 |
F401-1 | A290-0124-X002 | Lower | W series Axle for F401.401C Ref. A970-0124-X002 | |
 |
F401-2 | A290-8004-X713 | Φ49×6.5×6 | Lower | W series (Stainless housing+Plastic roller) |
| Various | |||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application |
 |
F401-3 | A97L-0124-X003 | Nut | W series Nut for wire sub roller F401 | |
 |
F401S | A290-8004-V316 | Φ49×6.5×6 | Lower | W series With axis +bearing Material : Stainless steel roller set |
 |
F401C | A290-8004-X713 | Φ49×6.5×6 | Lower | W series Stainless housing+White ceramic roller |
 |
F401CS | A290-8004-V316 | Φ49×6.5×6 | Lower | W series With axis+bearing Material : Ceramic roller set |
 |
F402 | A290-8006-X707 | Φ64×6.5×6 | Lower | W series Material : Stainless steel roller |
| F402S | A290-8006-X707 | Φ64×6.5×6 | Lower | W series Material : Stainless steel roller set | |
 |
F402BS | A290-8006-X707 | Φ64×6.5×6 | Lower | W series Material : Brass roller set |
 |
F402C | A290-8006-X707 | Φ64×6.5×6 | Lower | W series Material : Stainless steel roller |
 |
F402CS | A290-8006-X707 | Φ64×6.5×6 | Lower | W series Material : Stainless steel roller set |
 |
F403 | A290-8103-X762 | 40x40x25 | Lower | α-0A. 0B series Guide base from Stainless steel |
 |
F404 | A290-8110-X770 | 69x51x20 | Lower | α-0A. 0B series AWF & Manual type Guide block |
 |
F404-1 | A290-8101-X765 | Φ38xΦ22×12 | Lower | α-A. B. C. iA. iB series Material : Stainless steel roller |
 |
F404-1C | A290-8101-X765 | Φ38xΦ22×12 | Lower | α-A. B. C. iA. iB series Material : Ceramic roller |
 |
F405 | A290-8101-X394 | 13x20x19 | Feed section | α-A. B. C series Material : Plastic |
 |
F406 | A290-8110-Z382 | Φ40xΦ20×18 | Pinch roller | α-A. B series AWF & Manual type Material : Ceramic |
 |
F407 | A290-8101-Z383 | Φ40xΦ20×19 | Feed roller | α-A. B series AWF & Manual type |
 |
F408 | A290-8102-X393 | 57x20x20 | Feed guide | α-A. B. C series Manual type Polycarbonate feed wire guide |
 |
F409 | A290-8101-X371 | Φ140×22 | Upper | α-A. B. C series AWF & Manual type Brake shoe |
 |
F409i | A290-8111-X371 | Φ140×22 | Upper | α-A. iB series Brake shoe |
 |
F409w | A290-8011-V352 | Upper | O. P. Q. R. W series Brake shoe | |
 |
F409wo | A290-8039-V352 | Φ100×22 | Upper | W-0 series AWT type Brake shoe |
 |
F410 | A290-8110-X382 | Φ40xΦ28×30 | Roller | α-C series AWF & Manual type / Pinch roller |
 |
F411 | A290-8110-X383 | Φ40xΦ12×30 | Roller | α-C series AWF & Manual type / Feed roller |
 |
F412 | A290-8110-X762 | 46x40x24.5 | Base | α-C. iA. iB series AWF & Manual type / Guide base |
 |
F413 | A290-8112-X382 | Φ80×22 | Roller | α-iA. iB series AWF & Manual type / Pinch roller |
 |
F414 | A290-8112-X383 | Φ80×22 | Roller | α-iA. iB series AWF & Manual type / Feed roller |
 |
F500 | A97L-0001-0670 (SSLF1260ZZ) | Φ12xΦ6×4 | Bearing | Bearing 1260Z for F401 & F402 Replaced by A97L-0001-0986 |
| F501A | A97L-0001-0670 (DRF2280H) | Φ25xΦ8×7 | Bearing | α-A. B. C. iA. iB series AWF/Manual type / For F401-1 Without rubber seal | |
 |
F501B | A97L-0201-0369 (FL608LLB) | Φ25xΦ8×7 | Bearing | α-A. B. C. iA. iB series AWF/Manual type / For F401-1 With black rubber seal |
 |
F502 | A97L-0201-0369 (SS6001LLU) | Φ28xΦ12×8 | Bearing | α-A. B. C series For 406. 410. 417 With blue rubber seal |
| Various | ||||||||||||||||||||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application | |||||||||||||||||
 |
F503A | A97L-0201-0369 (SS6003LLU) | Φ35xΦ17×10 | Bearing | α-A. B series With blue rubber seal | |||||||||||||||||
 |
F503B | A97L-0201-0369 (SS6003LLU) | Φ35xΦ17×10 | Bearing | α-A. B series Without rubber seal Ref. A97L-0201-0910 | |||||||||||||||||
 |
F504 | A97L-0201-0369 (SS6203LLU) | Φ40xΦ17×12 | Bearing | α-A. B series With blue rubber seal Replaced to A97L-8101-X765 | |||||||||||||||||
 |
F505 (Fe415) | A290-8037-X331 | Φ80xΦ11×18 | Roller | O. P. Q. R. W series Material : Stainless steel / Feed roller | |||||||||||||||||
 |
F505C Fe415C | A290-8037-X331 | Φ80xΦ11×18 | Roller | O. P. Q. R. W series Material : Ceramic feed roller | |||||||||||||||||
 |
F506 Fe416 | A290-8037-X330 | Φ80xΦ20×18 | Roller | O. P. Q. R. W series Material : Stainless feed roller | |||||||||||||||||
 |
F506C Fe416C | A290-8037-X330 | Φ80xΦ20×18 | Roller | O. P. Q. R. W series Material : Ceramic feed roller | |||||||||||||||||
 |
F507 Fe417 | A290-8037-X805 | Φ60xΦ28×18 | Roller | W-0 series AWT type / Pinch roller | |||||||||||||||||
 |
F508 Fe418 | A290-8037-X806 | Φ80xΦ10×18 | Roller | W-0 series AWT type / Feed roller | |||||||||||||||||
 |
F509 Fe419 | Φ23xΦ12×12 | Upper | W-3 series Semi-AWT type / Ceramic roller | ||||||||||||||||||
 |
F510 Fe420 | A290-8032-V742 | Right | Roller assembly | ||||||||||||||||||
 |
F511 Fe421 | Φ39xΦ17×12 | W0 series AWT type | |||||||||||||||||||
 |
F512 Fe422 | Φ40xΦ14×12 | W0 series AWT type | |||||||||||||||||||
| F513 (Fe423) | A97L-0201-0910 | Φ38xΦ14×12 | Bearing | W0 series AWT type / Φ3.5×3 hole Ref. A97L-0201-6003 | ||||||||||||||||||
| F514 | A290-8021-Y701 | Φ12×8 | V guide | W-0 series AWT type / V ditch sapphire guide | ||||||||||||||||||
| F515 | A290-8021-Y712 | Φ10×19.5 | Shaft | W series Guide holder shaft | ||||||||||||||||||
 |
F516 Fe505 | A290-8110-X752 | Upper | α-0iA. 1iA series Upper screw | ||||||||||||||||||
 |
F517 Fe506 | A290-8112-X752 | Φ38xΦ14×12 | Upper | α-A. C series Upper screw | |||||||||||||||||
 |
F518 Fe507 | A290-8102-X657 | 6x6x10 Φ2.5 | Cutter | α-A. C series Cutting electrode | |||||||||||||||||
 |
F519 Fe508 | A98L-0001-0972 | 115x85x14 | Packing | α-iA. iB series Size : 4″ V packing | |||||||||||||||||
 |
F520 Fe509 | A98L-0001-0973 | 140x108x14 | Packing | α-iA, iB series Size : 6″ V packing | |||||||||||||||||
 |
F521 Fe510 | A290-8102-X656 | Chuck | α-A. C series | ||||||||||||||||||
 |
F522 Fe511 | A97L-0201-0911 | Bearing | α-A. C series SS6807LLU | ||||||||||||||||||
 |
F523 Fe512 | A290-8102-X684 | Cutter spring | α-A series | ||||||||||||||||||
 |
F524 Fe513 | Cutter spring | α-A. iC series | |||||||||||||||||||
 |
F525 Fe514 | A290-8110-X721 | Upper | α-A. C series Dies block | ||||||||||||||||||
 |
F526 Fe514-1 | A290-8102-X722 | Upper | α-C. iC series Dies block | ||||||||||||||||||
 |
F527 Fe515 | Spacer | ||||||||||||||||||||
 |
F528 Fe516 | A290-8102-X722 | Upper | α-A. B series Die guide base | ||||||||||||||||||
 |
F529 Fe517 | α-A. B series Bobbin scrap | ||||||||||||||||||||
| Various | |||||||||||
| Picture | Code No. | Orignal P/No. | Dimension | Position | Application | ||||||
| F530 Fe518 | A290-8102-X721 | α-A. B series Upper Block | |||||||||
| F531 | A290-8112-X656 | α-A. C series Chuck rubber | |||||||||
 |
F532 | A290-8032-V742 | Right | W-0 series Ceramic roller | |||||||
 |
F533 | A290-8032-V746 | Left | W-0 series Ceramic roller | |||||||
